Training Course: FDNE

Network equivalents are normally used in EMT type simulations to represent parts of power systems that are far from the area of interests for the current studies.

The training course will focus on:

   - Fundamentals of FDNE

       - Frequency dependent network equivalent branches

       - Transient Stability Analysis (TSA) models interfaced to EMT simulation

   - Curve fitting methods for FDNE branches, passivity and numerical stability

   - how to build an FDNE with a RSCAD/Draft file

   - how to build an FDNE with data extract directly from PSS/E data file

   - how to create a sib file automatically

   - how to validate an FDNE

Reference:

[1] Xi Lin, A. M. Gole, Ming Yu,

“A Wide-Band Multi-Port System Equivalent for Real-Time Digital Power System Simulators”,  IEEE TRANSACTIONS ON POWER SYSTEMS, VOL. 24, NO. 1, pp. 237-249, FEBRUARY 2009

URL: https://ieeexplore.ieee.org/document/4696025

[2] Z. Xiaofeng, Y. Shihao, Z. Desheng and S. Jie, "Research on application of FDNE based on RTDS and comparison analysis of fault transient of Shanghai Sijing power grid," in The Journal of Engineering, vol. 2019, no. 16, pp. 1393-1397, 3 2019, doi: 10.1049/joe.2018.8777.

URL: https://ieeexplore.ieee.org/stamp/stamp.jsp?tp=&arnumber=8694364&isnumber=8694216
